9000 BTU 23 SEER Mini Split Air Conditioner Inverter Heat Pump 110V Energy Star
9000 BTU 23 SEER Mini Split Air Conditioner Inverter Heat Pump 110V Energy Star
Couldn't load pickup availability
Why ENERGY STAR?
Earning the ENERGY STAR means products meet strict energy efficiency guidelines set by the U.S. Environmental Protection Agency. By choosing ENERGY STAR certified heating and cooling equipment and taking steps to optimize its performance, you can enhance the comfort of your home while saving energy. Saving energy helps you save money on utility bills and protect our climate by helping prevent harmful carbon pollution and reducing other greenhouse gases.
ENERGY STAR certified air conditioners have higher seasonal energy efficiency ratio (SEER) and energy efficiency ratio (EER) ratings and use 8 percent less energy than conventional new models.
You may get Government rebates if you chose our Energy Star product . welcome ask us!
Find rebates and special offers near you on ENERGY STAR certified products. Products that earn the ENERGY STAR
label meet strict energy-efficiency specifications set by the U.S. EPA helping you save energy and money while protecting the environment.
About this item
●WORKS WITH ALEXA: Use voice or app control to control your air conditioner from anywhere.Worls with wifi ,
●Ultra efficient cooling and heating 9,000 BTU/h capacity with 23 SEER Energy Star Certified AHRI Certified & ETL Certified
●Ultra capable performance: Heating during -13°F weather and cooling during 140°F weather Pre-Charged R-410A
●DESIGNED FOR HOME & BUSINESS: Powerful performance and dependable durability with high quality design for
●WHAT’S INCLUDED: Includes indoor air handler, outdoor condensers and installation kit with 16ft. line set and
|
Model |
ATPRO23-09H1B |
||
|
Type |
cooling&heating |
||
|
Control type |
remote |
||
|
Power supply |
115V~/60Hz/1P |
||
|
Rated Cooling |
Rated cooling capacity |
Btu/h |
9000 |
|
EER |
Btu/W.h |
12.5 |
|
|
SEER |
Btu/W.h |
23 |
|
|
Rated Heating |
Rated Heating capacity(47F/8.3C) |
Btu/h |
9500 |
|
Rated Heating capacity(17F/-8.3C) |
Btu/h |
6000 |
|
|
Rated Heating capacity(19F/-7C) |
Btu/h |
8000 |
|
|
HSPF Rating (Region IV) |
Btu/W.h |
10 |
|
|
HSPF Rating (Region V) |
Btu/W.h |
8 |
|
|
COP |
W/W |
3.5 |
|
|
COP (5℉/-15℃) |
W/W |
1.75 |
|
|
Rated Input Consumption |
Cooling |
W |
710 |
|
Heating |
W |
730 |
|
|
Rated Current |
Cooling |
A |
6.4 |
|
Heating |
A |
6.5 |
|
|
MXimum Operation Pressure |
PSIG |
550 |
|
|
Moisture removal |
Liters/h |
1.1 |
|
|
Indoor airflow |
m3/h |
650/550/450 |
|
|
1cfm≈1.7m3/h |
CFM |
382/324/265 |
|
|
Indoor noise level at cooling |
Turbo/High/Med./Low/Mute |
42/39/34/29/27 |
|
|
Outdoor airflow |
m3/h |
2100 |
|
|
1cfm≈1.7m3/h |
CFM |
1235 |
|
|
Outdoor noise level |
dB(A) |
50 |
|
|
Connecting Pipe |
Gas |
inches |
3/8'' |
|
Liquid |
inches |
1/4'' |
|
|
Connecting Wiring |
Size x Core number |
4×16AWG |
|
|
Net dimensions (W x D x H) |
Indoor |
mm |
820×306×195 |
|
inch |
32.28×12.05×7.68 |
||
|
Outdoor |
mm |
728x305x550 |
|
|
inch |
28.66x12.01x21.65 |
||
|
Net weight |
Indoor |
kg |
9 |
|
lbs |
19.8 |
||
|
Outdoor |
kg |
23.5 |
|
|
lbs |
51.8 |
||
|
Gross weight withou pipe |
Indoor |
kg |
11 |
|
lbs |
24.3 |
||
|
Outdoor |
kg |
25.5 |
|
|
lbs |
56.2 |
||
|
Refrigerant |
Type |
R410a |
|
|
g |
780 |
||
|
1oz=28.35g |
ozs |
27.51 |
|
|
Condenser |
mm |
Φ7x1 |
|
|
Additional refrigerant charge |
(g/m, oz/ft) |
20 / 0.22 |
|
|
Ambinet temperature |
Indoor(cooling/ heating) |
F |
62~89/32~86 |
|
Outdoor(cooling/heating) |
F |
5~122/-13~86 |
|
