24000 BTU 20 SEER Mini Split Air Conditioner Inverter Heat Pump 220V Energy Star

Name: 24000 BTU 20 SEER Mini Split Air Conditioner Inverter Heat Pump 220V Energy Star
Brand: The HVAC Supply
SKU: Energy Star 24000btu
Price: 1120.0 USD
Availability: InStock

$1,120.00 USD

~~$1,299.00 USD~~ $1,120.00 USD

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

About this item
●WORKS WITH ALEXA: Use voice or app control to control your air conditioner from anywhere.Works with WIFI ,

you can use app on your smart phone control your air conditioner from anywhere
●Ultra efficient cooling and heating 24,000 BTU/h capacity with 20 SEER Energy Star Certified AHRI Certified & ETL Certified

(Includes about 16 FT Line Set)
●Ultra capable performance: Heating during -13°F weather and cooling during 140°F weather Pre-Charged R-410A
●DESIGNED FOR HOME & BUSINESS: Powerful performance and dependable durability with high quality design for

an attractive appearance Ultra silent operation: as quiet as 27 dB on the indoor section and 52 dB on the outdoor unit
●WHAT’S INCLUDED: Includes indoor air handler, outdoor condensers and installation kit with 16ft. line set and

communication wire. Important note: requires professional installation.

SPEC

Model			ATPRO23-24H1B
Type			cooling&heating
Control type			remote
Power supply			208/230V~/60Hz/1P
Rated Cooling (95F/35C)	Rated cooling capacity	Btu/h	23000
	EER	Btu/W.h	12.5
	SEER	Btu/W.h	20
Rated Heating	Rated Heating capacity(47F/8.3C)	Btu/h	24000
	Rated Heating capacity(17F/-8.3C)	Btu/h	14000
	Rated Heating capacity(19F/-7C)	Btu/h	18000
	HSPF Rating (Region IV)	Btu/W.h	10
	HSPF Rating (Region V)	Btu/W.h	8
	COP	W/W	3.2
	COP (5℉/-15℃)	W/W	1.75
Rated Input Consumption	Cooling	W	1920
Rated Input Consumption	Heating	W	2050
Rated Current	Cooling	A	17.2
Rated Current	Heating	A	18.2
MXimum Operation Pressure		PSIG	550
Moisture removal		Liters/h	2.6
Indoor airflow		m3/h	1250/1050/900
Indoor airflow	1cfm≈1.7m3/h	CFM	735/618/529
Indoor noise level at cooling	Turbo/High/Med./Low/Mute		51/48/43/38/35
Outdoor airflow		m3/h	4500
Outdoor airflow	1cfm≈1.7m3/h	CFM	2647
Outdoor noise level		dB(A)	58
Connecting Pipe	Gas	inches	5/8"
Connecting Pipe	Liquid	inches	1/4''
Connecting Wiring	Size x Core number		4×16AWG
Net dimensions (W x D x H)	Indoor	mm	1100×333×222
	Indoor	inch	43.31×13.11×8.74
	Outdoor	mm	910x397x805
	Outdoor	inch	35.83x15.63x31.69
Net weight	Indoor	kg	14
	Indoor	lbs	30.9
	Outdoor	kg	47.5
	Outdoor	lbs	104.7
Gross weight withou pipe	Indoor	kg	16
	Indoor	lbs	35.3
	Outdoor	kg	54
	Outdoor	lbs	119.0
Refrigerant		Type	R410a
		g	1850
	1oz=28.35g	ozs	65.26
Condenser		mm	Φ7x2
Additional refrigerant charge		(g/m, oz/ft)	20 / 0.22
Ambinet temperature	Indoor(cooling/ heating)	F	62~89/32~86
Ambinet temperature	Outdoor(cooling/heating)	F	5~122/-13~86

Why ENERGY STAR?

Earning the ENERGY STAR means products meet strict energy efficiency guidelines set by the U.S. Environmental Protection Agency. By choosing ENERGY STAR certified heating and cooling equipment and taking steps to optimize its performance, you can enhance the comfort of your home while saving energy. Saving energy helps you save money on utility bills and protect our climate by helping prevent harmful carbon pollution and reducing other greenhouse gases.

ENERGY STAR certified air conditioners have higher seasonal energy efficiency ratio (SEER) and energy efficiency ratio (EER) ratings and use 8 percent less energy than conventional new models.

You may get Government rebates if you chose our Energy Star product . welcome ask us!

Find rebates and special offers near you on ENERGY STAR certified products. Products that earn the ENERGY STAR
label meet strict energy-efficiency specifications set by the U.S. EPA helping you save energy and money while protecting the environment.
