12000 BTU 19 SEER2 Ductless AC Mini Split Air Conditioner Heat Pump 110V Wifi

Name: 12000 BTU 19 SEER2 Ductless AC Mini Split Air Conditioner Heat Pump 110V Wifi
Brand: The HVAC Supply
SKU: 19 seers 12000btu 110v
Price: 599.0 USD
Availability: InStock

$599.00 USD

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

Item description

●WORKS WITH ALEXA: Use voice or app control to control your air conditioner from anywhere.Worls with wifi ,

you can use app on your smart phone control your air conditioner from anywhere

●Ultra efficient cooling and heating 12,000 BTU/h capacity with 19 SEER Certified AHRI Certified & ETL Certified

(Includes about 16 FT Line Set)

●Ultra capable performance: Heating during -13°F weather and cooling during 122°F weather Pre-Charged R-410A

●DESIGNED FOR HOME & BUSINESS: Powerful performance and dependable durability with high quality design for

an attractive appearance Ultra silent operation: as quiet as 34 dB on the indoor section and 52 dB on the outdoor unit

●WHAT’S INCLUDED: Includes indoor air handler, outdoor condensers and installation kit with 16ft. line set and

communication wire. Important note: requires professional installation.

-- Accessories that fit (Extra price)

SPEC

Model			AES19-12H1B
Power supply			115V~/60Hz/1P
Rated Cooling (95F/35C)	Rated cooling capacity	Btu/h	12000
	EER	Btu/W.h	10.5
	SEER	Btu/W.h	19.0
Rated Heating (47F/8.3C)	Rated Heating capacity	Btu/h	12000
	HSPF Rating (Region IV)	Btu/W.h	10.0
	COP	W/W	3.0
	COP (5℉/-15℃)	W/W	1.95
Input Consumption	Cooling	W	1140
Input Consumption	Heating	W	1170
Rated Current	Cooling	A	10.1
Rated Current	Heating	A	10.4
MXimum Operation Pressure		PSIG	650
MXimum Fuse Size		A	30
Moisture removal		Liters/h	1.6
Indoor noise level at cooling	Turbo/High/Med./Low/Mute		40/37/34
Outdoor noise level		dB(A)	52
Connecting Pipe	Gas	inches	3/8''
Connecting Pipe	Liquid	inches	1/4''
Connecting Wiring	Size x Core number		4×16AWG
Net dimensions (W x D x H)	Indoor	inch	31.92x11.49x8.07
Net dimensions (W x D x H)	Outdoor	inch	28.66x12.01x21.65
Net weight	Indoor	Ibs	19.8
Net weight	Outdoor	Ibs	65
Loading Capacity (IN+OUT)	40’HC (without pipe)		250
Loading Capacity (IN+OUT)	40’HC (with pipe)		234
Loading Capacity (IN)	40’HC/ 40'GP/ 20'GP		718/638/302
Loading Capacity (OUT)	40’HC/ 40'GP/ 20'GP(without pipe)		360/270/126
Loading Capacity (OUT)	40’HC/ 40'GP/ 20'GP(with pipe)		348/258/120
* Indoor Unit *
Indoor air circulation/Hi		m³/h	650
		CFM	380
* Outdoor Unit *
Outdoor air circulation/Hi		m³/h	2290
		CFM	1350
Factory Refrigerant charge(7.5m pipe)		g/oz	1002g / 35.34ozs
Factory Precharge Line		(m/ft)	7.5 / 25
MXimum Line Length		(m/ft)	15 / 50
MXimum Height Difference Between Indoor and Outdoor		(m/ft)	10 / 33
Additional refrigerant charge		(g/m, oz/ft)	20 / 0.22
Ambinet temperature	Indoor(cooling/ heating)	F	62.6~89.6/32~86
Ambinet temperature	Outdoor(cooling/heating)	F	5~122/-13~86
